Type: ETO Sterilization Equipments
Brand Name: FENGRONG
Model Number: HMQ-CE001
Place of Origin: Beijing, China (Mainland)
Volume: 1 m³,2 m³,3 m³,4.5 m³,6 m³,11 m³,15 m³,20 m³,
Carton materials: SUS 304 stainless steel
Temperature range: 0~100℃
Humidity range: 0~99%RH
Working pressure: -80kPa~ 80kPa
Max.power of electrical heating: 9~60 kW
Max.power of the humidifier: 3~9 kW
Power supply: 3-phase,4-line 380V; 50Hz
Packaging & Delivery
Packing Details: Wooden cases
Delivery Details: Shipped in 45 days after prepayment
Product Description
Product Application
1.Medical devices: cardiac pacemakers,artificial hearts,dialysis machines,suction apparatus,commutative components of oxygenation,automatic suturing machine for operation,sutures,suture needles,artificial esophagus,artificial bone,artificial blood vessels etc.
2. Endoscopes:laryngoscope, broncho scope,fiber scope for esophagus,mediastinoscope, cystoscope,urethra scope thoracoscope
3.Rubber products:gloves,fingertip,syringes,syringe needle,blood collection devices,infusion sets,urine collecting bag,hose in organ,nasal tube,conduits,suction hose,birth-control apparatus etc.
4.Pharmaceutical:Some Chinese& western medicine,some cosmetics
5.Textiles and biological products:cotton fiber clothing,blankets,carpets,gauze bandages,cotton balls,cotton swab,absorbent cotton,dressing type,towels,leather,fur products etc
6.Heritage archive:money note,tickets,medical records,files,epistle,historical relics,silk satin products,animial specimens etc.
7.Instruments:electronic equipment,optical instruments,telephone etc
8.Sanitary products:women sanitary napkins,napkins,disposable sanitary utensils etc
Features of product
1) The whole set is heated by a hexahedral way to assure the uniformity of temperature.
2) An independent auxiliary frame is adopted in order to install the equipment in separate rooms and guarantee the safety of use.
3) The whole sterilization process is monitored automatically throughout the process by the industrial control unit (ICU)
a) With a friendly man-machine interface
b) The sterilization parameter can be set random as the using situation
c) Two operational modes,i.e.,automatically control and manual control are available
d) Automatically control the EO to input temperature in order to assure the adequate gasification of EO
e) Automatically record the information of sterilization process, and the data sheet of temperature,humidity and pressure as well as curve diagrams
f) Automatically stop operation,produce sound & light alarm and words attention if any malfunction or technical deviation occurred during the process of operation
4) Automatically control the on/off of the door(translation type) and automatically inflating and sealing.
5) Machine doors:Easy to operate,usage safety
Part Number | Volume | dimension |
1m3 | Cabinet: Lx Wx H= 1400*700*1000 Overall:LxWx H= 1800*1200* 2000 | |
2m3 | Cabinet: Lx Wx H= 1650*1000*1200 Overall:LxWx H= 2050*1500* 2000 | |
3m3 | Cabinet: Lx Wx H= 2500*1000*1200 Overall:LxWx H= 2900*1500* 2000 | |
4.5m3 | Cabinet: Lx Wx H= 2150*1350*1550 Overall:LxWx H= 2600*1950* 2200 | |
6m3 | Cabinet: Lx Wx H= 2900*1350*1550 Overall:LxWx H= 3300*1950* 2200 | |
11m3 | Cabinet: Lx Wx H= 4850*1350*1700 Overall:LxWx H= 5300*1950* 2300 | |
15m3 | Cabinet: Lx Wx H= 4850*1350*2000 Overall:LxWx H= 6000*1950* 2600 | |
20m3 | Cabinet: Lx Wx H= 7500*1350*2000 Overall:LxWx H= 8000*1950* 2600 | |
25m3 | Cabinet: Lx Wx H= 9500*1350*2000 Overall:LxWx H= 10000*1950* 2600 | |
30m3 | Cabinet: Lx Wx H= 11000*1350*2000 Overall:LxWx H= 11500*1950* 2600 | |
